10.1″ HD monitor, Quad view (model MH991)


  • 10.1 ” touchscreen color digital display (1080P)
  • Multiple view monitor, 4 channels
  • Single, dual, triple, quad, trefoil display
  • Brightness automatic adjustment Day / night
  • 1 year warranty
  • Cable: 5m, 10m, 15m, 20m (option)
SKU: P73.2223 Category: Tags: , ,


  • 10.1” HD quad-view monitor with LVDS interface, support high resolution 1280*800.
  • Support 4 x camera inputs in 720P / 1080P and multiple TV system like PAL / NTSC / HD-AHD / HD-TVI / HD-CVI, and 1080P video input.
  • Image can be set to horizontally/vertically flipped, normal/mirror image; menu characters remain same while setting to mirror image.
  • Support multiple image display modes like single, dual, triplex, quad, trefoil, Y-split, H-split.
  • Support 1 x HDMI video input, for easy connection to PC or smart electronic devices, etc.
  • Support 1 x VGA video input and resolution can be 1080P.
  • Support 1 x CVBS video input for DVD.
  • Support Wi-Fi display for synchronous display on Mobile or tablet, etc.
  • Capacitive touch-screen.
  • Support 5 x triggers, trigger priority & trigger delay are selectable.
  • Support auto scan, scan channel and scan time are selectable.
  • Support backlight adjustment manually in 3 levels and automatically.
  • Parking line.
  • With 1.5W speaker.
  • Monitor operated by buttons, remote control or touch-screen.
  • Support 9 languages OSD (English, German, Japanese, Russian, Chinese, Italian, Spanish, French, Dutch).
  • Working voltage: 10-32V, with short circuit protection and short circuit alarm function.
  • Compliance with CE/FCC/EAMARK standards

Additional information

Weight 5 lbs
Dimensions 12 × 12 × 18 in
